Features

  • Low Phase Noise
  • Industry-standard SMD package
  • Supply voltage 5.0, 12.0 or 15.0 Volts
  • Available with Screening & Testing to MIL STD.

Typical Applications

Specifications

Frequency Range: 20.0kHz to 30.0MHz
Output: HCMOS
Input Voltage: Model ZT570: +5.0VDC±5% Model ZT571: +12.0VDC±5% Model ZT572: +15.0VDC ±5%
Input Current: 15mA typical (10MHz)
Ext. Frequency Control: (On pin 1) >±5ppm Positive slope
Ageing: ±1ppm /1st year
